Section 2 – SR-2 Hardware Description
COMMUNICATION PORTS
The SR-2 features three communication ports.
CargoWatch Port
The CargoWatch port is used to download the
CargoWatch data logger and to flash load software
to the HMI Control Panel. It is located on the control
panel next to the ServiceWatch port.
ServiceWatch Port
The ServiceWatch port is used to download the
ServiceWatch data logger and to flash load software
to the microprocessor. It is located on the control
panel next to the CargoWatch port.
Printer Port
This port is used to print trip records from the
CargoWatch data logger. It is located inside the
control box.
2-28
31 January 2005
