Section 3 – SR-2 Software Description
Sensor Configuration Menu –
CargoWatch Datalogger
The CargoWatch Datalogger is internal to the HMI
Control Panel. This datalogger conforms to
European standard EN12830. The data logger
supports up to 6 temperature sensors and 4 digital
inputs. These sensors are optional sensors and are
not the same as the temperature sensors used to
control the unit. Note that the CargoWatch data
logger does not record unit sensors. Unit sensors
and other unit operating data are recorded by the
ServiceWatch data logger.
Sensor Programming
Logging Interval
Micro Rev
All
HMI Rev
All
Choices
5 to 60 minutes in 5-minute intervals
Factory Set
15 Minutes
Exceptions Wintrac is capable of setting
additional intervals as short as 1 minute.
Description This feature allows the desired
logging interval to be set.
Log Sensor for CargoWatch sensor 1, 2, 3, 4, 5
or 6
Micro Rev
All
HMI Rev
All
Choices
ON or OFF
Factory Set
Sensors 1-2 ON, sensors 3-6 OFF
Exceptions
Description This feature allows the desired
sensors to be logged or ignored.
Independent Sensor Name for CargoWatch
sensor 1, 2, 3, 4, 5 or 6
Micro Rev
All
HMI Rev
All
Choices
See table below
Factory Set
Log Sensor 1 through 6
Exceptions
Description This feature allows the desired
sensor name to be specified. These names appear
only on handheld printer reports. This aids in
reading and understanding data logger printer
reports.
~ choices shown in next column ~
Choices
• Independent Sensor 1, 2, 3, 4, 5 or 6
• Return Air
• Return Air Zone 1, 2 or 3
• Other Return Air
• Discharge Air
• Discharge Air Zone 1, 2 or 3
• Other Discharge Air
• Spare Return Air
• Spare Return Air Zone 1, 2 or 3
• Other Spare Return Air
• Spare Discharge Air
• Spare Discharge Air Zone 1, 2 or 3
• Other Spare Discharge Air
• USDA 1, 2 or 3
• Spare USDA 1, 2 or 3
• Spare
• Other
• Other Spare
• Front
• Rear
• Side
• Right Side
• Left Side
• Spare Front
• Spare Rear
• Spare Side
• Spare Right Side
• Spare Left Side
• Fresh
• Frozen
• Chilled
• Dry
• Spare Fresh
• Spare Frozen
• Spare Chilled
• Spare Dry
• Ambient
• Spare Ambient
• Log Sensor 1, 2, 3, 4, 5 or 6
3-41
31 January 2005
