Section 3 – SR-2 Software Description
Sensor Averaging
Micro Rev
All
HMI Rev
All
Choices
ON or OFF
Factory Set
OFF
Exceptions
Description If this feature is turned OFF, the
temperature logged will be the actual instantaneous
sensor reading at the time of log. If this feature is
turned ON, the sensor is read once each minute.
The sensor readings are averaged dependant on
the setting of the Logging Interval feature selected
above.
For example, if the Logging Interval is 15 minutes
the previous 15 sensor readings are averaged and
logged instead of the actual instantaneous value. If
the Logging Interval is set for 10 minutes, the
previous 10 sensor readings are averaged and
logged.
Digital Input Programming
The digital inputs are used to log the door switch
status.
Digital In for CargoWatch digital input 1, 2, 3 or 4
Micro Rev
All
HMI Rev
All
Choices
Digital Input 1, 2, 3 or 4
Factory Set
Exceptions
Description This feature allows the digital input
to be programmed to be selected.
Door Open Logging
Micro Rev
All
HMI Rev
All
Choices
ON or OFF
Factory Set
Input 1 ON, inputs 2-4 OFF
Exceptions
Description This feature allows the desired
digital inputs to be logged or ignored.
Digital Input Name for CargoWatch digital input
1, 2, 3 or 4
Micro Rev
All
HMI Rev
All
Choices
See table below
Factory Set
Digital Input 1 through 4
Exceptions
Description This feature allows the desired
input name to be specified. This aids in reading and
understanding data logger downloads.
Choices
• Digital Input 1, 2, 3 or 4
• Door
• Other Door
• Main Door
• Back Door
• Front Door
• Side Door
• Left Door
• Right Door
• Other Back Door
• Other Front Door
• Other Side Door
• Other Left Door
• Other Right Door
• Fresh Door
• Other Fresh Door
• Frozen Door
• Other Frozen Door
• Chilled Door
• Other Chilled Door
• Dry Door
• Other Dry Door
3-43
31 January 2005
