Section 4 – SR-2 Operation
Sensor List
• Control Return Air Temperature
• Display Return Air Temperature
• Control Discharge Air Temperature
• Display Discharge Air Temperature
• Temperature Differential
• Evaporator Coil Temperature
• Ambient Air Temperature
• Spare 1 Temperature
• Datalogger Sensor 1 Temperature
• Datalogger Sensor 2 Temperature
• Datalogger Sensor 3 Temperature
• Datalogger Sensor 4 Temperature
• Datalogger Sensor 5 Temperature
• Datalogger Sensor 6 Temperature
• Board Temperature Sensor (HMI board)
