Section 2 – SR-2 Hardware Description
SR2 HMI Control Panel Connector Maps
HMI Control Panel Connector – arranged by use
Pin # Wire # Description
22 CANH-RED1-01 HMI Control Panel CAN bus
10 CANL-BLK1-01 HMI Control Panel CAN bus
06 8XP-BLK3-01 8F power
12 BLK2-02 2P power
34 ON_OFF-RED2-01 HMI Control Panel On/Off
35 CH RED3-01 HMI Control Panel chassis ground
23 DRAIN-WHT-01 HMI Control Panel drain
21 RXD2-01 CargoWatch receive
32 TXD2-01 CargoWatch transmit
19 COM2-01 CargoWatch chassis ground
09 DPD1-01 CargoWatch Data Pak Detect
20 RXD2-01 Printer port receive
31 TXD2-01 Printer port transmit
19 COM2-01 Printer port chassis ground
29 D14-01 Printer port print
12 2P Printer port printer power
04 S1P-01 CargoWatch sensor 1 positive
16 S1N-01 CargoWatch sensor 1 negative
27 S2P-01 CargoWatch sensor 2 positive
15 S2N-01 CargoWatch sensor 2 negative
03 S3P-01 CargoWatch sensor 3 positive
14 S3N-01 CargoWatch sensor 3 negative
26 S4P-01 CargoWatch sensor 4 positive
25 S4N-01 CargoWatch sensor 4 negative
02 S5P-01 CargoWatch sensor 5 positive
13 S5N-01 CargoWatch sensor 5 negative
01 S6P-01 CargoWatch sensor 6 positive
24 S6N-01 CargoWatch sensor 6 negative
2-8
31 January 2005
