Section 5 – SR-2 Diagnostics
62 AMMETER OUT OF CALIBRATION
Page 1 of 1
Alarm Type
Shutdown Alarm (Pretrip Only)
Associated Alarm
Codes
How Alarm is Set
Shunt calibration check in Pretrip Test shows shunt circuit is out of calibration with all outputs de-energized.
How Alarm is Cleared
This alarm is cleared manually.
Diagnostic Procedure
Check the microprocessor, using Service Procedure A01A.
5-57
02 February 2005
