Operation
Instrument Controls Menu
3-46 Model 48i Instruction Manual Thermo Electron Corporation
Concentrations The Concentrations screen allows the user to select the output signal that is
tied to the selected streaming data item. The selected item is shown by “<--”
after it.
• In the Main Menu, choose Instrument Controls > Communication
Settings > Streaming Data Config > Select Item > Concentrations.
• Use and to move the cursor up and down.
• Press to select a new choice.
• Press to return to the Choose Item Signal submenu or to
return to the Run screen.
XXLO WCONCENTRATIONXXLO W
CO 15.80 PPM
SAMPLE 12:34 ALARMx
CHOOSE ITEM SIGNAL:
CONCENTRATIONS
OTHER MEASUREMENTS
ANALOG INPUTS
RANGE AVG DIAGS ALARM
XXLO WCONCENTRATIONXXLO W
CO 15.80 PPM
SAMPLE 12:34 ALARMx
CONCENTRATIONS:
>NONE
CO <--
RANGE STATUS
RANGE AVG DIAGS ALARM
