Operation
Instrument Controls Menu
3-56 Model 48i Instruction Manual Thermo Electron Corporation
• In the Main Menu, choose Instrument Controls > I/O Configuration >
Output Relay Settings > Select Relay > Instrument State.
• Use and to move the cursor up and down.
• Press to select a choice.
• Press to return to the Output Relay Setup menu or to
return to the Run screen.
Alarms The Alarms status screen allows the user to select the alarm status for the
selected relay output. The selected item is shown by “<--” after it.
• In the Main Menu, choose Instrument Controls > I/O Configuration >
Output Relay Settings > Select Relay > Instrument State > Alarms.
• Use and for a list of choices.
• Press to save the new selection for the relay.
• Press to return to the Instrument State submenu or to
return to the Run screen.
XXLO WCONCENTRATIONXXLO W
CO 15.80 PPM
SAMPLE 12:34 ALARMx
CHOOSE SIGNAL TYPE:
>ALARMS
NON-ALARM
RANGE AVG DIAGS ALARM
