Operation
Instrument Controls Menu
Thermo Electron Corporation Model 48i Instruction Manual 3-57
Non-Alarm The Non-Alarm status screen allows the user to select the non-alarm status
for the selected relay output. The selected item is shown by “<--” after it.
• In the Main Menu, choose Instrument Controls > I/O Configuration >
Output Relay Settings > Relay 1-10 > Instrument State > Non-Alarm.
• Use and for a list of choices.
• Press to save the new selection for the relay.
• Press to return to the Instrument State submenu or to
return to the Run screen.
XHIGH RANGE CONCENTRATIONW
CO 15.80 PPM
SAMPLE 12:34 ALARMx
ALARM STATUS ITEMS:
>NONE
GEN ALARM <--
HI CO CONC
LO CO CONC
INT TEMP
BENCH TEMP
PRESSURE
ª
RANGE AVG DIAGS ALARM
FLOW
INTENSITY
MOTOR SPEED
BIAS VOLTAGE
MB STATUS
MIB STATUS
I/O BD STATUS
CONC ALARM
