Digital Input Settings The Digital Input Settings menu displays a list of the digital inputs
available, and allows the user to select the instrument parameter or logic
state to change for the relay selected.
Note The digital inputs must be asserted for at least one second for the
action to be activated. 
• In the Main Menu, choose Instrument Controls > I/O Configuration >
Digital Input Settings > 1-16.
• Use and to move the cursor up and down.
• Press to select a choice.
• Press to return to the I/O Configuration menu or to
return to the Run screen.
XXLO WCONCENTRATIONXXLO W
CO 15.80 PPM
SAMPLE 12:34 ALARMx
NON ALARM STATUS ITEMS:
>NONE
AUTORANGE <--
LOCAL/REMOTE
SERVICE
UNITS
ZERO MODE
SPAN MODE
ª
RANGE AVG DIAGS ALARM
SAMPLE MODE
CO MODE
