Operation
Instrument Controls Menu
3-70 Model 48i Instruction Manual Thermo Electron Corporation
Volts The Volts screen allows the user to set the input voltage for the selected table
point in the conversion table, from 0.00 to 10.50. The default table is a
two-point table with point 1: 0.00 V = 000.0 U and point 2: 10.00 V = 10.0
U.
• In the Main Menu, choose Instrument Controls > I/O Configuration >
Analog Input Config > Select Table Point > Volts.
• Use and to move the cursor up and down.
• Press to save the new value.
• Press to return to the Table Point submenu or to return
to the Run screen.
XXLO WCONCENTRATIONXXLO W
CO 15.80 PPM
SAMPLE 12:34 ALARMx
TABLE POINT 01 CONFIG:
>VOLTS 5.00
USER VALUE 10.800
RANGE AVG DIAGS ALARM
XXLO WCONCENTRATIONXXLO W
CO 15.80 PPM
SAMPLE 12:34 ALARMx
TABLE POINT 01 VOLTS:
CURRENTLY: 5.00
SET TO: 8.00 ?
©ª INC/DEC


 SAVE VALUE
RANGE AVG DIAGS ALARM
