Operation
Instrument Controls Menu
Thermo Electron Corporation Model 48i Instruction Manual 3-69
• In the Main Menu, choose Instrument Controls > I/O Configuration >
Analog Input Config > Select Channel > Table Points.
• Use and to move the cursor up and down.
• Press to save the new value.
• Press to return to the Analog Input Config menu or to
return to the Run screen.
Table Point The Table Point submenu allows the user to set up an individual table
point.
• In the Main Menu, choose Instrument Controls > I/O Configuration >
Analog Input Config > Table Point 1-10.
• Use and to move the cursor up and down.
• Press to select a choice.
• Press to return to the Analog Input Config menu or to
return to the Run screen.
XXLO WCONCENTRATIONXXLO W
CO 15.80 PPM
SAMPLE 12:34 ALARMx
NUMBER OF TABLE POINTS:
CURRENTLY: 2
SET TO: 10 ?
©ª INC/DEC


 SAVE VALUE
RANGE AVG DIAGS ALARM
