TOMARK, s.r.o.
Airplane Maintenance Manual
Chapter 05 Inspection and Maintenance
Page 36 Issue: 04.APR 2016
Scheduled Inspection
(50 h)
100 h/
annual
as
specified
Inspect nose gear steering push-pull rods and their
attachment. Lubricate rod ends as per Section 05-20-02
Lubrication Chart .
○
Demount the nose gear strut fairing.
○
Visually check the nose gear strut fairing for cracks and other
damage
○
Loosen nose wheel fairing and push upwords.
○
Visually check the nose wheel fairing for cracks and other
damage
○
Inspect nose gear fork for deformation, cracks in welding
seams or due to material fatigue or stress.
○
Check the condition of the static discharge wire.
○
Nose Landing Gear Wheels and Tires
Check the attachment of the wheel disk and its locking.
○
○
Inspect tires for cracks, cuts and condition.
○
○
Check the condition of the valve at the opening of the rim.
○
Inspect slip marks for proper alignment.
○
○
Visually check the wheel disk for cracks and deformities.
○
Check the play in the bearings and the free turning of the
wheels.
○
Finish
Reinstall the fairings after the inspection of the nose landing
gear is done.
○
Check tire pressure:
Nose Landing Gear 1.2 bar
○
○
Main Landing Gear
Visually check the condition of the landing gear legs for
cracks and signs of delamination.
○
○
