TOMARK Viper SD-4 RTC - Rivets Survey

TOMARK, s.r.o.
Airplane Maintenance Manual
Chapter20 Standard Practices-Airframe
Issue: Issue: 11.AUG 2016 Page 87
Type of rivets
Designation
Use
POP UP RIVET
EN 14588 series 1031 - 3,2x4,0
Fuselage, wing,
stabilizer,
elevator, rudder,
flaps, ailerons
POP UP RIVET
EN 14588 series 1051 - 3,0x8,0
POP UP RIVET
EN 14588 series 1051 - 4,0x13,0
POP UP RIVET
EN 14588 series 1051 - 4,0x16.0
POP UP RIVET
EN 14588 series 1051 - 4,0x20,0
POP UP RIVET
AVEX series 1002 - 3,2x8,0
POP UP RIVET
AVEX series 1002 - 4,0x10,0
POP UP RIVET
AVEX series 1004 - 3,2x8,0
POP UP RIVET
AVEX series 1004 - 3,2x12,2
POP UP RIVET
AVEX series 1604 - 4,0x11,2
POP UP RIVET
AVEX series 1661 - 3,2x9,5
POP UP RIVET
AVEX series 1691 - 3,2x6,0
POP UP RIVET
AVEX series 1691 - 3,2x7,9
POP UP RIVET
AVEX series 1691 - 3,2x11,2
POP UP RIVET
AVEX series 1691 - 3,2x12,0
POP UP RIVET
AVEX series 1691 - 3,2x14,0
POP UP RIVET
AVEX series 1691 - 4,0x8,0
POP UP RIVET
AVEX series 1691 - 4,0x 9,5
POP UP RIVET
AVEX series 1691 - 4,0x12,0
POP UP RIVET
AVEX series 1691 - 4,0x12,7
POP UP RIVET
AVEX series 1691 - 4,0x14,0
POP UP RIVET
AVEX series 1691 - 4,0x16,7
POP UP RIVET
AVEX series 1691 - 4,0x18,0
POP UP RIVET
SR series 1201 - 3,2x6,5
POP UP RIVET
SR series 1201 - 3,2x8,0
POP UP RIVET
AVINOX II series BE61 - 3,2x9,2
POP UP RIVET
AVINOX II series BE61 - 3,2x11,5
POP UP RIVET
AVINOX II series BE61 - 4,0x7,5
POP UP RIVET
AVINOX II series BE61 - 4,0x9,5
POP UP RIVET
AVINOX II series BE61 - 4,0x12,5
POP UP RIVET
HEMLOK series 2221 - 6,5x14,3
SOLID RIVET
DIN 661 - 4x20
SOLID RIVET
DIN 661 - 4x24
SOLID RIVET
Nit AN470AD5-14
Table 1 Survey of rivets used in airplane structure
In case that different replacement rivets are used than shown in the
Table 1 Survey of rivets used in airplane structure then rivet
dimensions must be identical with originally used rivets and material
of rivets must fulfil the same material characteristics.
