Regular Inspection and Adjustment
MERGE 2-8
Chapter 2
9. Install
· Brake drum
· Rear wheel
WARNING:
Verify that there is no oil or water on the surface of
the brake drum and shoe block.
10. Install:
Wheel nuts
Tightening torque to
90N·m (66.4ft·1b)
NOTICE:
First, screw on the wheel nuts by hand, and then
tighten the nuts diagonally.
11. Upon the completion of the installation, step on the
brake pedal about 10 times to adjust the clearance
between the shoe plate and the drum.
