Electric Component
MERGE 9-17
Chapter 9
Removal of inner mirror
1.Take out the key from the key switch.
2. Apply the parking brake
3. Turn Tow/Run switch to TOW.
4.
Take off the connector of inner mirror
5.
Take off fixed nut of inner mirror
6.
Take out the mirror
Installation of inner mirror
1. Stick the sponge glue and clip on the bracket
of inner mirror
2. Fix the bracket on windshield frame
3.
Take off white lense
4.Fix the mirror on the bracket
