Electric Component
MERGE 9-18
Chapter 9
5 Cover the light with white lense.
6.fix the wire clip on the windshield frame
along left side of it.
7.connect the connector( connect one
side of the two output of connector of
inner mirror with wire, the other side with
the output wire of wiper
8. fix the wires of inner mirror along the
wire clip
