Topcon ALADDIN - Map Option

ALADDIN - User manual Rev. 23 of 08/07/2016
103
ISO
2005
Map Option
Map Design
Select one or more items with which to personalise the map display:
 Meridians
 3 Zones
 Ruler
 Grid
Keratometry
Select one of the keratometric indices:
 Sim-K
 Meridians
 Emimeridians
 3-5-7 mm or 2-4-6 mm, selects the 3 Zones diameters to which the Meridians or Emimeridians values
are displayed
Pupillometry
Select one or more items with which to personalise the display of the pupil images:
 Grid
 Ruler
 Ring center: the center of the pupil (in blue) and the fixation point (in red) will be displayed
 Pupil: the outline of the pupil will be displayed in blue
