Topcon ALADDIN - Technical specifications; General; Electrical data

ALADDIN - User manual Rev. 23 of 08/07/2016
135
15 Technical specifications
No modification of this equipment is allowed
NOTE: the manufacturer shall provide, upon request, circuit diagrams. the list of components, descriptions,
calibration instructions or other information that will assist the technical assistance personnel in the repair
of parts of the device specified by the manufacturer as repairable by the technical support staff.
NOTE: For the isolation of the device from the mains power, the device has a master switch that removes
all power from the device, and a plug connection to high voltage which performs the same function as the
previous one.
15.1 General
Corneal topography
Keratometry conus
24 rings equally distributed in a 43D sphere
Points analyzed
Over 100,000 points
Points measured
Over 6,200 points
Corneal coverage
Up to 9.8 mm on a sphere of 8mm radius (42.2 dioptres with n=1.3375)
Focusing system
Guided focus
Pupillometry
Measuring method
Image analysis
Light source
Infrared and white light LED
Axial length
Measuring method
Low-coherence interferometry on optical fiber
Light source
SLED @ 830nm
Axial length range
From 15mm up to 38mm
Anterior chamber
measurement
Measuring method
Slit light projection
Light source
Blue LED
NB: The parts in contact with the patient (applied parts) are the forehead rest in teflon and the chin rest
in acrylonitrile butadiene styrene resin (ABS)
15.2 Electrical data
Power supply
AC 100-240V 50/60 Hz
Power consumption
<150 VA
Onboard fuses
2x T2.5°
