Topcon ALADDIN - Other Components

ALADDIN - User manual Rev. 23 of 08/07/2016
24
Figure 4
9.2 Other components
Figure 5
NB: The parts in contact with the patient (applied parts) are the forehead rest in Teflon and the chin rest
in acrylonitrile butadiene styrene resin (ABS)
ON/OFF button
Forehead rest
Chin rest
Locking pins for
chin rest papers
Wheel for adjusting
the rest position
USB ports (2)
Power connector
(with fuse carrier)
LAN port
