Topcon ALADDIN - Checking the calibration

ALADDIN - User manual Rev. 23 of 08/07/2016
34
• Shammas No-history: Shammas H.J., Shammas M.C., Garabet A., Kim J.H., Shammas A. , LaBree
L.: Correcting the Corneal Power Measurements for Intraocular Lens Power Calculations After
Myopic Laser In Situ Keratomileusis” - American Journal of Ophthalmology (Impact Factor: 4.02).
10/2003; 136(3):426-32.
• Shammas No-history: Shammas H.J., Shammas M.C., Hill W.E.:Intraocular lens power calculation
in eyes with previous hyperopic laser in situ keratomileusis” - J Cataract Refract Surg 2013;
39:739–744 Q 2013 ASCRS and ESCRS.
These formulae are for use in patients who have had prior refractive surgery. Each such patient is unique
and results may vary widely. You should interpret all IOL power recommendations with caution.
General instructions
On the various screens displayed by the software there are symbols that provide access to certain functions
available in several working environments.
Access to the "Settings" section, described in detail in the dedicated paragraph.
Direct printing of the report or saving a PDF file depending on the options selected in the print
section.
13.2 Checking the calibration
The calibration must be checked when the device has been transported from one place to another
and when it has suffered an impact or thermal shocks.
Check the calibration of the device every day before starting patient examinations.
Set the calibration tool supplied with the device (Figure 14) in the special holes in the chin rest and press until
the tool is blocked on the device. Check that the calibration tool is perfectly aligned with the device. If the
calibration tool is positioned correctly, all the rings of the Placido disk should be seen reflected in the center
on the surface of the hemisphere (Figure 15).
Figure 14
