fields (Gender and ID are optional). You can set from the settings environment to have only the ID as required
field.
13.3.1 Creating a new patient
To create a new patient, select the “New” tab and enter the data using the on-screen keyboard. Once you
have entered the new patient data, click on the “Ok” button or select the “Acquisition” tab to confirm the
information and continue with the examination. If you want to empty all the fields click on the “Clear” button.
Before going into the acquisition environment, additional information on the patient is required, in particular
the presence and type of crystalline and the nature of the vitreous body (Figure 22).
An external keyboard or another input device compatible with “keyboard wedge interface” (PS/2) such as
barcode or card reader can be connected to the device to input text. The user must assure that the desired
textbox is under focus before the input action.
Before connecting an external device, such as a computer, printer, monitor, keyboard, mouse or other
devices, make sure that they comply with the EN 60950-1 standard and have the CE marking.
Entering special characters
A special character can be entered simply by touching and holding the corresponding letter as shown in
Figure 21:
Figure 21
Selecting crystalline and vitreous body type
Once the patient identity record has been created, it is possible to select the type of cristallyne and vitreous
humor for each patient’s eye, by pressing the “Acquisition” button (please see the following Figure 22)
