Diameter: Pupil diameter for the frame selected
Pupil Center (frame): Cartesian coordinates of the center of the pupil for the frame selected
Photopic, Mesopic
By clicking on the “Photopic”, “Mesopic” buttons static pupillometry acquisitions will be displayed, with the
following information:
Value of the average pupil diameter measured in all the images acquired during the sequence
The other information is the same as that already described for the dynamic pupillometry.
Functions
Graphs
Pressing the “Graphs” button displays the graphs relating to the pupil. This function is explained in the next
paragraph.
Delete
Pressing the “Delete” button, the system cancels the current pupillometry frame and the data it contains.
Graphs
In this section three types of graph are displayed:
Decentralization (Figure 68)
Latency (Figure 69)
Statistics (Figure 70)
In all these graphs you can select which eye you want to analyze by clicking on “OD” or “OS”.
The “Close” button closes the graphs.
