ALADDIN - User manual Rev. 23 of 08/07/2016
27
Open the internal box and remove the specially shaped cardboard that holds the instrument. The instrument
can now be taken out of the package. The steps are illustrated in Figure 9.
Figure 9
Be careful when taking ALADDIN HW3.0 out of the box gripping it by the chin rest arch and the base
beside the joystick.
Remove the Nylon cover.
Place the instrument on a flat surface.
Completely unscrew the two transportation locks and the semi-lock (Figure 10).
Connect the power cable provided. The instrument is now ready for use.
