ALADDIN - User manual Rev. 23 of 08/07/2016
49
Figure 30
Wheel for
adjusting the
chinrest height.
The position of the chin rest
must be both comfortable and
correct, i.e. it must allow the
person performing the
measurement to center
correctly on the fixation LED.
Make sure the
patient's forehead is
well up against the
forehead rest.
