Appendix B
P/N 7010-0557 www.topconpositioning.com
B-1
Specifications
This TPS product is a 20-channel GPS receiver with an internal
spread spectrum radio, a Bluetooth wireless technology module,
and a rugged aluminum housing complete with MINTER and cable
connectors.
Receiver Specifications
Table B-1 lists receiver component details.
Table B-1. Receiver Specifications
Component Details
Receiver Type (set by activating the proper OAF)
Euro-80 GD G – GPS L1
GD – GPS L1/L2
Euro-112 (HE_GGD) G: GPS L1
GD: GPS L1/L2
GG: GPS/GLONASS L1
GGD: GPS/GLONASS L1/L2
Tracking Specifications
Standard Channels Euro-80 GD – 20 channels (G, GD)
Euro-112 GGD – 20 channels (G, GG, GD, GGD)
L1 GPS, L1/L2 GPS, L1 GLONASS, L1 GPS + L1
GLONASS, WAAS/EGNOS
Optional Cinderella days (see page B-10 for details)
Tracked Signals GPS/GLONASS, L1/L2 C/A and P-Code and
Carrier, WAAS/EGNOS
