Topcon HiPer Lite - Receiver Configuration Settings

Receiver Configuration
P/N 7010-0557 www.topconpositioning.com
2-17
Receiver Configuration
You use PC-CDU to configure the various parts of the receiver. Any
settings you make using PC-CDU will be saved in the receiver’s
memory, and will be reflected when you use the MINTER. The full
range of PC-CDU configuration and function is outside the scope of
this manual.
TIP
TIP
Refer to the PC-CDU User’s Manual to manage all
possible receiver configurations.
The following configuration is recommended for the most common
applications. However, you can select configuration parameters as
needed for your particular jobsite.
NOTICE
NOTICE
Click Apply after making any configuration change,
otherwise your receiver will not accept the change.
1. Connect your receiver and computer. See “Connecting the
Receiver and a Computer” on page 2-11 for this procedure.
2. Once connected, click ConfigurationReceiver
(Figure 2-14).
Figure 2-14. Configure Receiver
