Receiver Specifications
P/N 7010-0557 www.topconpositioning.com
B-3
Frequency modulation
technique
FSK, 64 Kbps
System gain 140 dB
Network topology Point-to-point, Point-to-multipoint
Radio Transmitter
Output power 250 mW (24 dBm)/1 W (30 dBm), user-selectable
Radio Receiver
Sensitivity -110 dBm at 10-4 BER
Dynamic range 110 dB
Radio Data Communications
Serial interface RS-232
Serial data rate 9600, 19200, 38400, 57600 bps, user-selectable
Effective radio link
rate
9600, 12000, 17000, 24000, 51000 bps, user-
selectable
Error correction FEC (15,7), majority decoding
Radio Antenna
Type 1/2 wave articulating whip
Connector Reverse-polarity TNC
Gain 2.5 dBi
Table B-1. Receiver Specifications (Continued)
