Chapter 3
P/N 7010-0557 www.topconpositioning.com
3-1
Setup and Survey
This chapter describes:
• Receiver setup
• RTK Base station setup
• RTK Rover setup
• Basic surveying with the HiPer Lite or HiPer Lite+ receiver
The HiPer Lite and HiPer Lite+ packages use one receiver as the
Base station and the other as the Rover station.
Receiver Setup
To set up the receivers, you must:
1. Configure the receivers as shown in Chapter 2.
2. Set up the Base and Rover stations. See “Step 1: Set up the
Receiver” on page 3-2.
3. Measure the antenna height. See “Step 2: Measure Antenna
Height” on page 3-2 for internal antennas.
4. Begin collecting data. See “Step 3: Collect Data” on page 3-4.
All receivers include an internal, micro-strip antenna able to capture
L1/L2 signals from GPS and GLONASS satellites.
