Getting Acquainted
P/N 7010-0557 www.topconpositioning.com
1-11
• FLoader User’s Manual
• MINTER User’s Manual
• BTCONF User’s Manual
Getting Acquainted
The HiPer Lite/HiPer Lite+ receiver is 159mm wide, 172mm deep,
88mm high, and weighs approximately 1.74kg. The receiver’s
advanced design allows users to significantly reduce the number of
cables required for receiver operation, with the ability to perform
jobs more reliably and efficiently, especially when moving.
The receivers are also versatile and can be configured in several
different ways. The casing allocates space for two nonremovable,
on-board Li-Ion batteries, a Bluetooth wireless technology module,
and two Euro cards. One of those cards is the GPS receiver and the
other is used for spread spectrum communications. Table 1-1
compares the primary differences between the two receivers.
See Table 1-3 on page 1-14 for a description of the operating times
for the HiPer Lite and HiPer Lite+ receivers. For receiver
specifications, see Appendix B.
Table 1-1. HiPer Lite vs. HiPer Lite+
Components
and Options
HiPer Lite HiPer Lite+
User interface 4-light MINTER 4-light MINTER
Ports Serial A, B, C, D, PWR Serial A, B, C, D, USB, PWR
Receiver board Euro-80 Euro-112
GPS L1, L1/L2 L1, L1/L2
GLONASS n/a L1, L1/L2
Memory Standard: 0 MB
Optional: 1 MB up to 512 MB
Standard: 0 MB
Optional: 1 MB up to 1 GB
