Getting Acquainted
P/N 7010-0557 www.topconpositioning.com
1-19
Back Panel
Figure 1-7 shows the back panel components for the HiPer
Lite and HiPer Lite+; components are the same for both
receivers.
Figure 1-7. HiPer Lite and HiPer Lite+ Back Panels
• Vent plug – Equalizes the pressure between the inside
of the receiver and the outside environment.
• Slant height measure mark (SHMM)
Slant Height Measure Mark
Vent Plug
