Configuration
Topcon HiPer Lite and HiPer Lite+ Operator’s Manual
2-16
Figure 2-12. USB Connection Parameters
Once a PC-CDU connection with the receiver has been
established, the current communications settings—such as, port
name, baud rate (if applicable), and flow control (if applicable)
—display in the lower-left corner of the main window of
PC-CDU. A timer begins to count up in the lower-right corner
as well (Figure 2-13).
Figure 2-13. PC-CDU Connection Established
