Toro Field Pro 6040 - Air Cleaner

AirCleaner
g398768
Figure12
1.Clampassembly
5.Intakeelbow
2.Bracket6.Element,aircleaner
3.Body,aircleaner
7.Cap.aircleaner
4.Pipeplug
8.Vactuatorvalve
RemovingandInstallingtheAirCleaner
RefertoFigure12forthisprocedure.
1.Parkthemachineonalevelsurface,engagetheparkingbrake,setthekey
switchtotheOFFpositionandremovekeyfromtheswitch.
2.Lowertheoperatorcushiontogainaccesstotheaircleanercomponents.
3.Removetheaircleanercomponentsasneeded.
4.RefertothetractionunitOperator’sManualforaircleanerserviceand
maintenanceprocedures.
IMPORTANT
Anyleaksintheaircleanersystemwillallowthedirtintotheengine
andwillcauseseriousenginedamage.Ensurethatallaircleaner
componentsareingoodconditionandareproperlysecuredduring
assembly.
5.Examinetheaircleanerhousingandcoverforwearanddamagethatcould
causepossibleairleaks.Replacecomponentsifnecessary.
6.Examinetheairintakehoseforwearordamageandreplacethehoses
ifnecessary.
