ServiceProcedureIcons
ThefollowingiconsappearthroughoutthisServiceManualtobringattentionto
specicimportantdetailsofaserviceprocedure.
CriticalProcess
Thisiconisusedtohighlight:
•installingsafetyequipment(shields,guards,seatbelts,brakesandR.O.P .S.
components)thatmayhavebeenremoved
•dimensionsorsettingsthatmustbemaintainedforpropermachineoperation
•aspecicfastenertighteningsequence
•componentorientationthatmaynotbeobvious
CriticalTorque
Thisiconisusedtohighlightanassemblytorquerequirementthatisdifferent
thanwhatisrecommendedintheStandardTorqueT ables;refertoStandard
TorqueforDry,ZincPlated,andSteelFasteners(Inch)(page2–8)orStandard
TorqueforDry,ZincPlated,andSteelFasteners(MetricFasteners)(page2–10).
FluidSpecications
Thisiconisusedtohighlightuidspecicationsandcapacitiesthatareless
common,andmaynotappearonthemachineservicedecalorinthemachine
Operator’sManual.
Note:RefertotheservicedecalonthemachineandthemachineOperator’s
Manualforcommonlyuseduidspecicationsandcapacities.
