3.2 PARALLEL INTERFACE
(1) Type : Centronics
(2) Mode : Conforms to IEEE1284 compatible mode
(3) Data Input Method : Parallel 8 bits (DATA1 ~ 8)
(4) Control Signals : ACK, BUSY, SELECT, DATA • STB, FAULT, PE, INIT (Not used),
AUTOFD (Not used), SELECTIN (Not used)
(5) Data Input Code : ASCII code
European character set 8 bit code
Graphics 8 bit code
(6) Receive Buffer : 16 K bytes
(7) Connector : Printer
Amp. Japan 552742-1 or equivalent
DDK 57RE-40360-73B or equivalent
Cable
Amp. Japan 552470-1 or equivalent
DDK 57E-30360 or equivalent
