Toshiba B-EV4 Series User Manual

- 85 -
[RSS-14 Limited]
[RSS-14 Expanded]
When the bar code height is 0000, bar code (including guard bars) and numerals
under bars are not drawn. However, the bar code printed on the previous label is
cleared.
(8) Length of guard bar
The length of guard bar is valid only when the type of bar code is WPC.
It is ignored in any other cases.
Height of bar code
Length of guard bar
Height
Height

Toshiba B-EV4 Series Specifications

General

Print Method	Direct Thermal / Thermal Transfer
Power Supply	AC 100-240V, 50/60 Hz
Operating Temperature	5°C to 40°C
Print Resolution	203 dpi, 300 dpi
Max Print Speed	Up to 127 mm/sec (5 ips) (203 dpi) / Up to 101.6 mm/sec (4 ips) (300 dpi)
Interface	USB, Serial
Optional Interfaces	Wireless LAN
Weight	2.4 kg
Barcodes	Code 39, Code 128
2D Codes	Data Matrix, PDF417, QR Code, Maxi Code
Media Width	25.4 mm to 112 mm
Media Thickness	0.06 mm to 0.19 mm
Media Roll Diameter	Max. 127 mm
Ribbon Width	40 mm to 110 mm
Ribbon Length	300 m
Operating Humidity	25% to 85% non-condensing
