Toshiba B-EV4 Series - Rectangle

- 35 -
[Rectangle]
(1) Radius of rounded corners = 000 or parameter omitted
(2) Radius of rounded corners ≠ 000
Notes (1) In line designation, a horizontal line, vertical line, or slant line A/B is drawn
according to the start and end point coordinates.
(2) The result is the same even if the start and end point coordinates are reversed.
(3) The start and end point coordinates must be set so that the result of line drawing
will be within the effective print area set by the Label Size Set Command ([ESC]
D).
(X
1
,Y
1
)
(X
2
,Y
2
) (X
1
,Y
1
)
(X
2
,Y
2
)
Line width
Line width
Line
width
Line width
Radius
(X
2
,Y
2
)
Line width
Line width
(X
1
,Y
1
)
