Toshiba B-EV4 Series - Commands for System Administrator; Parameter Set Command

- 173 -
6.3.32 PRINTER INFORMATION REQUEST COMMAND [ESC] IR
Function Retrieves the printer information.
Format [ESC] IR [LF] [NUL]
Explanation (1) The model name and serial No. set by the Printer Information Store Command
([ESC] IG) are retrieved
[Information field]
Model name Serial No.
20 bytes 11 bytes
Examples The following information is stored in the printer.
Model name: B-EV4D-GS14-QM-R
Serial No.: 2303A000001
Model name:
[42H] [2DH] [45H] [56H] [34H] [44H] [2DH] [47H] [53H] [31H] [34H] [2DH] [51H] [4DH] [2DH]
[52H] [20H] [20H] [20H] [20H]
Serial No.: [32H] [33H] [30H] [33H] [41H] [30H] [30H] [30H] [30H] [30H] [31H]
Refer to Printer Information Store Command ([ESC] IG)
