Toshiba B-EV4 Series - Effective Print Area

- 32 -
[Effective print area] [mm]
Model 203 dpi 300 dpi
Item Issue mode Batch Strip Cutter Batch Strip Cutter
Min. 13 13
Effective print width
Max. 108± 0.2 105.7± 0.2
Min. 6 21.4 17.4 6 21.4 17.4
Label
Max. 995 148.2 991 453.2 148.2 449.2
Min. 8 --- 25.4 10 --- 25.4
Effective print
length
Tag
Max. 997 --- 997 455.2 --- 455.2
Examples
[ESC] XR; 0345, 0100, 0762, 0585, A [LF] [NUL]
[ESC] RC000; ABC [LF] [NUL]
[ESC] RC001; DEF [LF] [NUL]
[ESC] XS; I, 0001, 0002C3000 [LF] [NUL]
10.0 mm
58.5 mm
34.5 mm
76.2 mm
Origin (0, 0)
Start point of
designated area
Effective print area
Designated area
End point of designated area
