Toshiba B-EV4 Series User Manual

- 149 -
• How to assign the directory name for a writable character set
Directory name for writable character 01 → “0100”
Directory name for writable character 02 → “0101”
Directory name for writable character 39 → “0126”
Directory name for writable character 40 → “0127”
Directory name for writable character 51 → “0200”
Directory name for writable character 55 → “0204”
• How to assign the file name
0100 0022. UDF (Writable character 40: writable character file for character code 22H)
Identifier indicating the writable character file
Character code (2-byte code: Code 22H)
Writable character set (Writable character 40: Same as the directory name)

Toshiba B-EV4 Series Specifications

General

Print Method	Direct Thermal / Thermal Transfer
Power Supply	AC 100-240V, 50/60 Hz
Operating Temperature	5°C to 40°C
Print Resolution	203 dpi, 300 dpi
Max Print Speed	Up to 127 mm/sec (5 ips) (203 dpi) / Up to 101.6 mm/sec (4 ips) (300 dpi)
Interface	USB, Serial
Optional Interfaces	Wireless LAN
Weight	2.4 kg
Barcodes	Code 39, Code 128
2D Codes	Data Matrix, PDF417, QR Code, Maxi Code
Media Width	25.4 mm to 112 mm
Media Thickness	0.06 mm to 0.19 mm
Media Roll Diameter	Max. 127 mm
Ribbon Width	40 mm to 110 mm
Ribbon Length	300 m
Operating Humidity	25% to 85% non-condensing
