(5) Issue speed * Duplicate printing feature is supported only by the 203 dpi model.
• Printing takes place at the designated speed.
• The possible issue speed varies according to types and sizes of the paper
supply. For details, refer to the Supply Specification.
Issue speed
Model
203 dpi model 300 dpi model
Issue mode
Parameter
C: Batch D: Strip E: Strip C: Batch D: Strip
E:
Strip
1
2
2”/sec 2”/sec 2”/sec 2”/sec 2”/sec 2”/sec
3 3”/sec 3”/sec 3”/sec 3”/sec 3”/sec 3”/sec
4 4”/sec 4”/sec 4”/sec
5
6
7
8
9
5”/sec 5”/sec 5”/sec
4”/sec 4”/sec 4”/sec
A
Max. 2”/sec. or
5”/sec.
(Depending on a
duplicate printing area
setting for duplicate
labels)
B
Max. 5”/sec.
(When using
duplicate labels and
no duplicate printing
is necessary.)
Not guaranteed.
Printing is performed according to the issue speed parameter settings:
1 to 9: Normal printing on normal labels
A: Duplicate printing on duplicate labels
B: Normal printing on duplicate labels

Toshiba B-EV4 Series Specifications

General

Print Method	Direct Thermal / Thermal Transfer
Power Supply	AC 100-240V, 50/60 Hz
Operating Temperature	5°C to 40°C
Print Resolution	203 dpi, 300 dpi
Max Print Speed	Up to 127 mm/sec (5 ips) (203 dpi) / Up to 101.6 mm/sec (4 ips) (300 dpi)
Interface	USB, Serial
Optional Interfaces	Wireless LAN
Weight	2.4 kg
Barcodes	Code 39, Code 128
2D Codes	Data Matrix, PDF417, QR Code, Maxi Code
Media Width	25.4 mm to 112 mm
Media Thickness	0.06 mm to 0.19 mm
Media Roll Diameter	Max. 127 mm
Ribbon Width	40 mm to 110 mm
Ribbon Length	300 m
Operating Humidity	25% to 85% non-condensing
