- 159 -
Notes (1) The print origin of coordinates must be set so that the result of drawing the
graphic data will be within the effective print area set by the Label Size Set
Command ([ESC] D).
(2) The number of graphic width dots and the number of graphic height dots must
also be set so that the result of drawing the graphic data will be within the effective
print area set by the Label Size Set Command ([ESC] D) in the same manner as
the above.
(3) Both width and height are 8 dots/mm.
(4) The actual result of drawing may deviate within ±0.33 mm in the X direction with
respect to the designated print origin of the X-coordinate.
To draw the received graphic data at high speed, the data is directly
developed in the image buffer without applying correction to each bit with
respect to the designated X-coordinate. Consequently, an error of up to 4
bits occurs.
[Effective print area] [mm]
Model 203 dpi 300 dpi
Item Issue mode Batch Strip Cutter Batch Strip Cutter
Min. 13 13
Effective print width
Max. 108± 0.2 105.7± 0.2
Min. 6 21.4 17.4 6 21.4 17.4
Label
Max. 995 148.2 991 453.2 148.2 449.2
Min. 8 --- 25.4 10 --- 25.4
Effective print
length
Tag
Max. 997 --- 997 455.2 --- 455.2
