ERROR CODE AND TROUBLESHOOTING
8 - 36
8.3 Diagnosis and Prescription for Each Error Code
8.3.1 Check item
8.3.2 Paper transport jam
[E010] Paper not reaching fuser transport sensor
Check item Contents
Sensor check • Check the sensor in the test mode.
• Check that there is no dust on the sensor.
• Check that the actuator is correctly operated.
Connector check
• Check that the connector is not disconnected.
• Check that the pins are not deformed and do not come off.
• Disconnect and reconnect the connector.
Harness check Check if the harnesses are open circuited.
Motor check
• Check the motor in the test mode.
• Check that there is no abnormality in the driving section.
• Check that there is no abnormality in the roller.
Board check Check if the board is short circuited or open circuited.
Classification Error item
Paper exit jam Paper which has passed the fuser unit does not reach the fuser transport
sensor
Check item Measures
Fuser transport sensor • Sensor check (Perform the input check: 03-[FAX]OFF/[7]/[C])
• Connector check
• Harness check.
LGC board • Connector check (CN332, CN339, CN341)
• Board check.
Transfer belt unit • transfer belt check
• transport motor driving PC board
Fuser • Connector check
• Harness check.
Drive unit, Rollers • Gear check
• Roller check
Drum separation finger solenoid • Motor check (Perform the output check:03-111/161)
• Harness check.
R
egistration sensor
• Sensor check (Perform the input check: 03-[FAX]ON/[4]/[E])
• Connector check
• Harness check.
Registration motor
• Motor check (Perform the output check:03-108/158)
• Harness check.
Replace parts Remarks
Fuser transport sensor
Drum separation finger solenoid
