Toshiba TECRA A11 Series User Manual

Tests and Diagnostics
TECRA A11/S11/P11/Satellite Pro S500 Series Maintenance Manual (960-784) [CONFIDENTIAL] 3-107
3.34.4.4 Display of Test Result
If the test ends successfully or the [STOP] button is clicked, the following Result screen is
displayed.
After confirming the result, click the [CLOSE] button to close the screen.
After the display of the test result screen, the test result logs are saved to X drive.
Note: WinPE is extracted on the RAM disk on drive X. Therefore, if the PC is shut down,
the log files will be lost. It is recommended that necessary log files should be stored
in an external media according to the procedure described in section 3-4-5.
3.34.4.5 Test Log Management Screen
If you press the [LOG] button on the Diagnostics screen, the following log management
screen opens. This function saves test log files to the specified storage.
1) Display of log file
If you click on the log file name displayed on the screen, the content of the log file is
displayed in the text format.

Toshiba TECRA A11 Series Specifications

General

RAM	Up to 8GB DDR3
Operating System	Windows 7 Professional
Battery Life	Up to 4 hours
Optical Drive	DVD SuperMulti Drive
LAN	Gigabit Ethernet
Processor	Intel Core i3, i5, or i7
Display	15.6-inch HD (1366x768)
Storage	HDD up to 500GB
Graphics	Intel HD Graphics
Wireless	802.11 a/g/n
Webcam	Integrated webcam
Ports	USB 2.0, VGA, RJ-45
Card Reader	SD
Battery	6-cell Li-ion
Dimensions	374 x 250 mm
Chipset	Mobile Intel QM57 Express Chipset
