Printrex
®
980 Specifications and Requirements
100-11672 - Rev D Page 95
Electrical Specifications
100 VAC - 240 VAC, 50-60 Hz
650 watts maximum
Media Specifications
Paper
Paper feed method Friction feed
Paper width 9.25 inches
Paper thickness 0.003 - 0.0035 inches
USB Interface
The USB interface is a Version 2.0 interface card is implemented through a
standard Series "B" receptacle as defined in the USB Specification. The
printer is self-powered and does not draw power from the standard Type B
USB interface cable.
The standard USB Type B connector has the following pin functions:
Pin Signal
1 Vbus (+5 V dc) (Not used in the Printrex
®
980)
2 Minus data
3 Plus data
4 Ground
Note: The standard USB interface does not have sufficient power to run the
printer.
