TransAct Printrex 980 - Work at Printhead Replacement; Work at Purge Unit Replacement

Appendix B: Frequently Asked Questions
Page 144 100-11672 - Rev D
Work at Printhead Replacement
Head Position Adjustment
1) Adjust Head position. ("Head Position Adjustment" section)
Work at Purge Unit Replacement
Blade Position Adjustment
1) Loosen the screw by 1 turn.
2) Set the key pins on holder of Blade with Blade Adjustment Tool.
Set Blade Adjustment Tool in Print Module.
