Step-by-Step Installation Instructions
100-11672 - Rev D Page 35
[8] Paper residual quantity lamp
On No paper.
Blinking The remaining amount of paper is low. (Only when sheets
are supplied through Feeder Lift Tray. Lamp starts flashing
when remaining papers become about 100 sheets).
Off Sufficient paper or during paper feed from rear feeder slot.
[9] ERROR lamp
On Operator-call error (can be recovered by user operation).
Blinking Fatal error.
Off Normal.
[10] STATUS lamp
On Online mode.
Blinking Data being received (printing, cleaning, initializing,
shut-down).
Off Printing is not possible (during error, sleep, pause etc.).
Note: Never turn off the main power switch during a print job. This could
cause damage, because the printhead cannot return to the home position.
Note: Never attempt to open the Upper unit by force or hit the door. This could
damage the printer or result in poor print quality. Always open and close the
Upper unit slowly.
