38
INSTALLATION INSTRUCTION
FLORAL CASE BAFFLE INSTALLATION
Evaporator
Housing
Baffle
The baffle is installed on floral cabinets to slow the velocity of the air down. This will make the flowers last
longer, because the pedals do not dry out as quickly.
1. Trim a small square out of top left side of baffle to accommodate the suction line.
2. Place baffle in place and install #6 x 1/2 screws into 1/2” lip of the baffle and top of cabinet.
3. Install #6 x 1/2 screws into 1/2” lip and evaporator cover being careful not to puncture evaporator drain pan.
