REQUIRED TOOLS
• Drill With 1/8" Bit
• 1/4" Nut Driver
• Exacto Knife or Razor Blade Knife
___________ STEP 1 ___________
Remove left side door by lifting up and
out of bottom track.
___________ STEP 2 ___________
Position ratchet bar over left side of
right hand door, centered top to bot-
tom. (see figure 1.)
___________ STEP 3 ___________
Drill through pilot hole in ratchet bar
and into door frame with 1/8" drill bit.
Anchor by installing 1/4" hex head
screw (provided).
CAUTION
Do not drill beyond 3/4" to avoid
hitting glass insert.
___________ STEP 4 ___________
Using an Exacto knife or razor blade
carefully cut rubber gasket along the
edges of the ratchet bar.
___________ STEP 5 ___________
Replace left side door and check slide
operation.
NOTE:
Ratchet bar may have to be bent in
slightly so not to impede
operation of left hand door.
___________ STEP 6 ___________
To lock cabinet, slide ratchet lock onto
ratchet bar through slot (lock should be
oriented with slot towards top of lock).
(see figure 2.)
Figure 2
INSTALLATION INSTRUCTION
RATCHET LOCK & PLASTIC DOOR STOP - SLIDE DOOR
Figure 1
