INSTALLATION INSTRUCTIONS
Glass Insert Gas Release (High Altitude Installation)
Required tools:
- Phillips head screwdriver
- 3/8” Wide double sided tape
- 1/16” Drill Bit
- Drill
- Silicone
__________ STEP 1 __________
Slide left door (door positioned on
outside track) to the right. Lift door
up and pull out at the bottom. Right
door (door positioned on inside track)
can be removed in the same manner.
__________ STEP 2 __________
Remove the nylon cord from the top
of the door.
__________ STEP 3 __________
Set the door (handle side down) on
a flat surface.
__________ STEP 4 __________
Remove the screws that secure the
four glass insert holders to the door.
Remove all four aluminum pieces.
__________ STEP 5 __________
Beginning at the corners carefully
pry the broken glass loose from the
frame. If necessary use heat gun or
hair dryer aimed in the space
between glass insert and door frame
to lessen resistance of double-sided
tape.
__________ STEP 6 __________
Carefully use the drill with a 1/16”
drill bit to drill through the spaces
between the glass.
__________ STEP 7 __________
After gas is released from in
between both panes use the silicone
to reseal drill holes.
__________ STEP 8 __________
Remove any excess tape or glass
from the lip on the door frame.
Replace with new double-sided
tape on the 1/2” lip.
__________ STEP 9 __________
Remembering to keep the tempered
glass to the handle side of the frame
place the new glass insert inside the
frame and press against the two-way
tape. (The etched TRUE logo is
positioned on the tempered glass
s i d e . )
__________STEP 10 __________
Replace the four Aluminum glass
insert holders.
__________ STEP 11 __________
Reconnect the nylon cord to the top
of the door and replace the door as
originally removed.
with 1/16” drill bit.
of glass.
